Victron SmartSolar MPPT RS 450/200-MC4 VE.Can

Overview

The Victron SmartSolar MPPT RS 450/200-MC4 VE.Can is a high-voltage, ultra-efficient solar charge controller designed for large-scale 48V battery systems. With up to 11.5kW of charging power, this MPPT controller is ideal for both on-grid and off-grid applications requiring maximum battery performance, flexibility, and safety.

Key Features

Ultra-Fast MPPT Tracking:
Continuously optimizes solar panel performance by rapidly tracking the maximum power point under varying conditions.
High PV Input Capacity:
Accepts up to 450V DC input with a startup voltage of 120V, supporting large PV arrays with ease.
Supports up to 4 MPPT Inputs:
Optimizes energy harvest across multiple PV strings independently.
Massive Charging Power:
Offers up to 200A output current, capable of delivering 11.5kW at 57.6V.
VE.Can & VE.Direct Communication:
Seamless integration with Victron GX devices for monitoring, data logging, firmware updates, and system control.
Bluetooth Connectivity:
Configure and monitor your system via VictronConnect app on mobile devices.
Smart Safety & Protections:
- PV disconnection protection
- Ground fault and DC bus protection
- Type II DC SPD & Type III AC SPD
- PV isolation resistance monitoring
- Programmable relay (e.g., genset start/stop)
Advanced Monitoring & Remote Access:
Supports connection to Victron VRM Portal for real-time data and remote management.
Robust Build Quality:
- Fan-assisted cooling
- Operates in temperatures from -40°C to +60°C
- Steel casing with IP21 protection

Technical Specifications

Battery Voltage: 48V
Max Charge Current: 200A
Max PV Input Voltage: 450V
MPPT Operating Range: 80–450V
Start-up Voltage: 120V
Max Efficiency: 96%
Communication Ports: VE.Direct, VE.Can, Bluetooth
Dimensions: 487 x 434 x 146 mm
Weight: 13.7 kg
Mounting: Wall-mounted

Compatibility & Use Cases

Ideal for large residential, commercial, or industrial solar systems requiring:

Multi-string PV arrays
High battery charging power
Remote system visibility and control
Integration with Victron inverters and battery monitoring systems

Weight	13.7 kg
Dimensions	48.7 × 43.4 × 14.6 cm
Brand:	Victron SmartSolar
Product Type:	MPPT
Color:	Blue
Weight:	13.7 kg
Dimensions:	487 x 434 x 146 mm
